RM-R800WP Series Radar Level Transmitter

The RM-R800WP is an ideal sensor for non-contact level measurement in simple applications. It is especially suitable for open channel applications and is commonly used in water and wastewater facilities, stormwater basins, and dam level monitoring systems.

Kategoriler: Seviye

Açıklama

Operating Frequency	77 GHz – 81 GHz
Measuring Range	max. 30 m
Measurement Accuracy	±2 mm (for liquids)
Beam Angle	±3.5°
Housing Material:	PP (Polypropylene)
Process Connection	Threaded or flanged options DIN and ANSI (on request)
Process Temperature	-40°C … 80°C
Process Pressure	Normal atmospheric pressure
Signal Output	4–20 mA / RS485 / Bluetooth
Supply Voltage	2-wire DC 24V (22V–30V)
